Features:

• 6 SIP identities / accounts
• XML browser
• Call lists for dialed, received, missed calls
• Local directory with 1000 entries
• Multiple language support
• DTMF in-band / out-of-band / SIP-INFO
• Interoperable with all major IP PBX platforms

Call Features:

• Speed dialing
• URL dialing
• Local dial plan
• Automatic redial on busy
• Call completion (busy/unreachable) (2)
• Caller identification
• Call waiting
• Call blocking (deny list)
• Auto answer
• Hold
• Music on hold (2)
• Blind and attended transfer
• Call forwarding
• 3-way conferecning on the phone
• Extension monitoring, call pickup (2)
• Call park, call unpark (2)
• Multicast paging
• DND mode (do not disturb)
• Keyboard lock
• Client matter code (CMC) (2)
• Unified Communications ready

Audio:

• Codecs:
  • G.711 A-law, µ-law
  • G.722 (wideband)
  • G.726, G.729AB, GSM 6.10 (FR)
• Built-in assignable ringtones
• Comfort Noise Generator (CNG)
• Voice Activity Detection (VAD)

Setup:

• Configurable through web interface
• Provisioning:
  • Automatic loading of settings via HTTP/HTTPS/TFTP
  • DHCP Redirection Service
  • Remote management via TR-069/TR-111

Protocols:

• SIP (RFC3261)
• HDCP, NTP
• HTTP/HTTPS/TFTP
• LDAP (Directory)
• Dual Stack IPv4 / IPv6

User Interface:

• Localization (language, time, dial tone)
• Red LED for call indication / message waiting
• 4 context-sensitve keys
• 3 programmable line / function keys with multicolour LEDs
• Dedicated keys for: Message, DND, Directory, Menu, Transfer, Hold, Page
• Audio keys with LED indication: Mute
• Speakerphone, Headset
• Volume key
• 5-way naviagation key
• OK and Cancel keys
• Automatic backlight enabled

Security:

• 802.1X authentication and EAPOL
• Transport layer security (TLS)
• SRTP (RFC3711), SIPS, RTCP
• HTTPS server/client
• password-protected web interface
• VPN-support
• VLAN (IEEE 802.1Q)
• LLDP-MED, RTCP-XR

Phone Features:

• Dimensions (approx.):
  • 205 x 185 x 40mm (LxWxD) w/o foot stand
  • 205 x 185 x 200/220mm (LxWxD) with foot stand
• Weight (approx.) device 710g, footstand 120g
• Input voltage: 5Vdc (SELV)
• Power supply: PoE or 5Vdc power adapter (1), 10 Watts
• Handset: 4P4C
• Headset: 4P4C Support for Snom EHS Advanced (1)
• Hearing -Aid compatible (HAC) handset
• 1xUSB 2.0 host port, Type A
• Environmental conditions:
  • Ambient temperature: 0°C to 35°C (32°F to 95°F)
  • Storage temperature: -10°C to 45°C (14°F to 113°F)
  • Humidity: 5% to 95% (non-condensing)
• Included in delivery:
  • Phone unit
  • Footstand
  • Handset with cord
  • Ethernet cable
  • Quick Start Guide
• Colour: Black or white

Type Approvals:

• CE Mark
• Safety IEC 60950

(1) Optional accessory (see below for part numbers)

(2) If supported by PBX
