Ubiquiti Switch Enterprise 8 PoE 120W 8x 2,5Gb + 2x 10Gb SFP+

Layer 3, PoE switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.

The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3* switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.The USW Enterprise 8 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

(1) 1.3" LCM color touchscreen with AR switch management
(8) 2.5GbE, 802.3at PoE+ RJ45 ports
(2) 10G SFP+ ports
120W total PoE supply
Wall-mountable (kit included)

* Layer 3 switching will become available in a future firmware update.

Managed with the UniFi Network application: Version 6.3.51 and later

Mechanical

Dimensions	200 x 248 x 44 mm
Weight	2.4 kg
Enclosure Materials	Polycarbonate
Mount Material	Polycarbonate

Hardware

Total Non-Blocking Throughput	40 Gbps
Switching Capacity	80 Gbps
Forwarding Rate	59.52 Mpps
Max PoE Power	120W
Power Method	(1) 100-240VAC, 2A Max., 50/60 Hz, Universal Input
Power Supply	AC/DC, Internal, 150W
Management Interface	Ethernet In-Band
Networking Interfaces	(8) 1/2.5 Gbps RJ45 Ethernet
SFP+ Interfaces	(2) 1/10 Gbps SFP+
PoE Interfaces	(8) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Max. PoE+ Wattage per Port by PSE	32W
Voltage Range 802.3af Mode	44 to 57V
Voltage Range 802.3at Mode	50 to 57V
Services	SMB Layer 3* PoE Gigabit Ethernet Switch Layer 3 feature will be available in the future firmware release.
LCM Display	(1) 1.3" Touchscreen Bootup Animation: Bootup in Progress Firmware Upgrade Icon: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted
ESD/EMP Protection	Air: +/- 16 kV, Contact: +/- 12 kV
Operating Temperature	-5 to 45 C
Operating Humidity	10 - 90% Noncondensing
Certifications	CE, FCC, IC
