Die Bewertung dieses Produkts ist von 5
225,-
185,95 exkl. MwSt.
Veilig achteraf betalen via of
Vandaag voor 17:00 besteld is morgen of maandag in huis
Zum Warenkorb hinzufügen Zur Wunschliste hinzufügen
|
UA-Hub |
|
|
Dimensions |
190 x 126 x 33 mm (7.48 x 4.96 x 1.29") |
|
Weight |
457 g (16.12 oz) |
|
Enclosure Characteristics |
Plastic Enclosure with Metal Mount Plate |
|
Mounting Options |
DIN Rail |
|
Networking Interface |
(4) 1 Gbps Ethernet |
|
Max. Power Consumption |
40W |
|
Power Method |
802.3bt PoE |
|
Input Relays |
REX - Request to Exit REN - Request to Enter REL - Remote Release DPS - Door Position Sensor |
|
Dry Output Relay Lock |
Rated 30VDC, up to 1A Rated 30VDC, up to 1A |
|
Powered Output Relay Lock |
12VDC, up to 1A 12VDC, up to 0.33A 12VDC, up to 0.33A |
|
LEDs |
(1) System, (3) PoE Out, (4) Input (2) Output Relays, (1) 12VDC Out |
|
Buttons |
Terminal Blocks, Reset |
|
Operating Temperature |
0 to 40° C (32 to 104° F) |
|
Operating Humidity |
5 - 90% Noncondensing |
|
Certifications |
CE, FCC, IC |
|
Recommended Wiring for Typical Installation (Shielded) |
|
|
DC Power Input |
Belden 8750, 18 AWG, 2 Conductor (30.5 m / 100 ft) |
|
Door Position Switch |
Belden 8750, 18 AWG, 2 Conductor (152.5 m / 500 ft) |
|
Request to Exit |
Belden 8750, 18 AWG (up to 152.5 m / 500 ft) |
|
Lock Relay Output |
Belden 8750, 18 AWG (up to 152.5 m / 500 ft) |
|
Auxiliary Relay Output |
Belden 8750, 18 AWG (up to 152.5 m / 500 ft) |
