2N Access Unit 2.0 Bluetooth & RFID

677,75

560,12 Excl. btw

2× op voorraad

Veilig achteraf betalen via of

Vandaag voor 17:00 besteld, morgen of maandag in huis!

Interfaces
Power supply:	PoE and/or 12 V/1 A DC
PoE:	802.3af (Class 0–12.95 W)
LAN:	10/100BASE-TX with Auto-MDIX, RJ-45 modular jack

Recommended cabling:	Cat-5e or better
Active switch output:	8 to 12 V DC/max 600 mA
Passive switch:	NO/NC contacts, up to 30 V/1 A AC/DC
Inputs:	2 inputs - in passive/active mode (-30 V to +30 V DC)

	OFF = open or Uin> 1.5 V
	ON = short-circuit or Uin< 1.5 V
Tamper switch:	native part of the 2N Access Unit 2.0
Audio:	buzzer (97dBA)
Supported protocols:	DHCP opt. 66, SMTP, TFTP, HTTP, HTTPS, Syslog
Bluetooth Reader
Version	compatible with Bluetooth 5.0 (BLE)
Range	(short - typically up to 3m, long - typically up to 10m)
	*distances should serve only as an approximate guide and may vary depending on the phone model and installation environment
Security	RSA-1024 and AES-128 encryption
RX sensitivity	up to -93 dBm
Mode	touch, tap in app, card
Mobile Application Support
	Android 6.0 and higher, iOS 12.0 and higher

RFID Card Reader
Supported frequencies	125 kHz and 13.56 MHz variant
Supported card types	card type compatibility depends on Order No.
125 kHz	EM4xxx
	HID Prox – versions with 125 kHz support and S in Order No. Only
13.56 MHz	ISO14443A, PicoPass (HID iClass), FeliCa, ST SR(IX), NFC (2N® Mobile Key)
	reads UID (CSN) and secured MIFARE® DESFire® EV2/EV3 cards using 2N® PICard technology
Secured 13.56 MHz	ISO14443A (MIFARE® DESFire®), PicoPass (HID iClass), FeliCa, ST SR(IX), NFC (2N® Mobile Key), HID SE (Seos, iClass, MIFARE SE)
	reads secured MIFARE® DESFire® EV2/EV3 cards using 2N® PICard technology
	reads PACs ID (HID iClass cards with SIO object)
Mechanical Properties
Frame:	robust zinc cast frame with surface finish (nickel and black color)
Operating temperature:	-40°C to +60°C
Storage temperature:	-40°C to +70°C
Operating relative humidity:	10%-95% (non-condensing)
Dimensions
Wall (surface) mounting frame:	1 module: 107 (W) x 130 (H) x 28 (D) mm
Flush mounting frame:	1 module: 130 (W) x 153 (H) x 5 (D) mm
Flush mounting box (minimum hole):	1 module: 108 (W) x 131 (H) x 45 (D) mm
Weight:	max 0.8 kg
Cover rating:	IP54 and IK08
