Features

• 5 Megapixel high-performance CMOS
• Auto focus
• 2.7-13.5mm motorized vari-focal lens
• 2560 × 1944 resolution
• EXIR 2.0, smart IR, up to 80 m IR distance
• OSD menu, 3D DNR, 130 dB true WDR
• IP67
• 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
• Up the Coax(HIKVISION-C)

Specifications

Camera

• Image Sensor: 5 megapixel progressive scan CMOS
• Signal System: PAL/NTSC
• Effective Pixels: 2560 (H) × 1944 (V)
• Min. Illumination: Color: 0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time: 1/25(1/30) s to 1/50,000 s
• Lens: 2.7 mm to 13.5 mm motorized vari-focal lens
• Lens Mount: ?14
• Adjustment Range: Pan: 0° to 360°; Tilt:0° to 90°; Rotate: 0° to 360°
• Day& Night: IR cut filter with auto switch
• Video Frame Rate: PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps; NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps
• Synchronization: Internal Synchronization

Menu

• 3D DNR (Digital Noise Reduction): Level 1 to 9
• D/N Mode: Auto/Color/BW (Black and White)
• Auto White Balance: Auto / Manual
• BLC: Support
• AGC: Support
• WDR: Yes
• Language: English
• Function: Brightness, Sharpness, DNR, Mirror, Smart IR

Interface

• Video Out: 1 HD analog output

General

• Operating Conditions:
  • -40 °C - 60 °C (-40 °F - 140 °F)
  • Humidity 90% or less (non-condensing)
• Power Supply: 9.6 VDC to 14.4 VDC; 19.2 VAC to 28.8 VAC
• Weather Proof: IP67
• IR Range: Up to 80m
• Communication :
  • Up the coax
  • Protocol: HIKVISION-C(Coaxitron)
• Dimension: 84.5 mm × 92 mm × 255.1 mm (3.33" × 3.62" × 10")
• Weight: Approx. 930 g (2.05 lb.)
