MCore Pro, Gen-3 Mini-PC

• 11th Gen Intel® Core i5
• Memory: 8 GB (2 x 4GB)
• Storage: 128 GB SSD
• 3x HDMI video output with CEC supported
• TPM2.0
• Kernel DMA
• EDID
• Wi-Fi: IEEE 802.11 a/b/g/n/ac/ax
• Bluetooth: BT 5.2
• 1 x Yealink MTouch port (RJ45), connect to MTouch Plus / MTouch E2
• 4 x USB 3.0 Type-A
• 1 x 10/100/1000M Ethernet port
• 1 x Power port
• 1 x Security lock slot, Integrated cable management

MTouch Plus

• 11.6-inch narrow bezel IPS display
• 1920 x 1080 video resolution
• Angle between screen and desktop (30° ~ 70°)
• Adjustable angle of support frame (50° ~ 180°)
• Support wired and wireless (with WPP30) content sharing
• Support multi-screen control*
• Support third-party screen sharing*
• Support external PD power supply to power the sharing device
• Support HDMI/USB-C video input
• Support desktop placement, desktop fixed, wall-mounted deployment

RoomSensor

• Detection angle: 120°
• Adjustable detection angle: ±20°
• Operating temperature: 0-40℃
• Operating humidity: 10-95%
• Power: Battery powered, 4 year life

AVHub, audio and video processor

• 2 x USB-A port
• 1 x USB-B port
• 1 x Codec port
• 7 x Yealink VCH port(RJ-45)
• 1 x RCA in/out interface
• 1 x 6.3mm Line in interface
• 1 x 6.3mm Line out interface
• 1 x power interface
• Dividable and merging meeting rooms are supported
• Support intelligent multi-speaker tracking
• Support wireless BYOD*

UVC86 USB PTZ Camera

• 4K Sensor
• 20.4 × HD zoom (12x optical, 1.7x digital)
• Angle of view:
-90° DFOV, 81° HFOV, 50° VFOV ( Telephoto lens)
-120° DFOV, 110° HFOV, 78° VFOV (Panoramic lens)
• Auto-framing
• Speaker tracking
• Presenter tracking, support area trigger and gesture control
• Multi-focus
• Picture-in-picture
• Up to 9 preset positions can be set
• Horizontal rotation: 200°
• Vertical rotation: 130°
• 1 x HDMI output
• 1 x Yealink microphone port(RJ-45)
• 1 x USB 3.0 Type-B port
• 1 x USB 2.0 Type-A Port
• 1 x Power Port
• 1 x Security Lock
• 1 x Reset Hole
