MikroTik netPower 16P outdoor 16 port PoE Switch, 2 SFP+

Powering a bunch of access points or IP cameras and a few uplinks on a tower has never been easier. netPower 16P has 16 Gigabit Ethernet ports with PoE-out and two SFP+ ports for 10G fiber uplinks. Its sturdy and compact outdoor enclosure allows the switch to be mounted in all kinds of environments - from damp attics and shafts to towers, masts and poles with hose clamps.

netPower 16P has a non-blocking throughput of 36 Gbps, switching capacity of 72 Gbps and forwarding rate of 53.6 Mpps. Device itself does not have an onboard voltage converter. You need 24V PSU to have 24V PoE out and/or 48V PSU to have 48V PoE out (IEEE 802.3 at/af).

LET OP: Power supply is NOT included with the product. You are welcome to use your preferred power option, like battery pack etc. Compatible also with MikroTik power supplies 24HPOW, 48POW and 48V2A96W.

Specifications

Architecture	ARM 32bit
CPU	98DX226S
CPU core count	1
CPU nominal frequency	800 MHz
Dimensions	303 x 212 x 78 mm
RouterOS license	5
Operating System	RouterOS/SwitchOS
Size of RAM	256 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-40 C to 70 C

Number of DC inputs	2 (DC jack)
DC jack input Voltage	18-30 V / 48-57 V
Max power consumption	316 W
Max power consumption without attachment	16 W
FAN count	Passive
PoE-out ports	Ether1-Ether16
PoE out	802.3af/at
Max out per port output (input < 30 V)	1.1 A
Max out per port output (input > 30 V)	0.6 A
Max total out (A)	2.8A (18V-30V) & 1.4A (48V-57V) x2 A

10/100/1000 Ethernet ports	16
Number of 1G Ethernet ports with PoE-out	16
SFP+ ports	2
CPU temperature monitor	Yes
Voltage Monitor	Yes
Certification	CE, EAC, ROHS
IP	IP54
