De beoordeling van dit product is van de 5
225,-
185,95 Excl. btw
Veilig achteraf betalen via of
Vandaag voor 17:00 besteld, morgen of maandag in huis!
Toevoegen aan winkelwagen Aan verlanglijst toevoegen
Mechanical:
| Dimensions | 190 x 126 x 30.5 mm (7.5 x 5 x 1.2") |
| Weight | 457 g (1 lb) |
| Enclosure material | Plastic enclosure with metal mount plate |
| Mounting options | DIN rail |
Hardware:
| Networking interface | (4) 1 GbE |
| PoE interface | (3) PoE (Pins 1, 2+; 3, 6-) |
| Power method | PoE++ UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| Supported voltage range | 48V DC |
| Max. power consumption | 51W |
| Total available PoE | 60W |
| Max. PoE wattage per port | 15.4 |
| Voltage range PoE mode | 44–57V DC |
| Input terminals | REX: request to exit REN: request to enter REL: remote release DPS: door position sensor |
| Dry output relay | Lock: rated 30V DC, up to 1A Aux: rated 30V DC, up to 1A |
| Powered output relay | Lock: 12V DC, up to 1A Aux: 12V DC, up to 0.33A Line: 12V DC, up to 0.33A |
| Button | (1) Factory reset |
| Operating environment | Indoor use only |
| Ambient operating temperature | 0 to 40° C (32 to 104° F) |
| Ambient operating humidity | 5 to 90% noncondensing |
| Software information | The software version of a product can be checked at https://unifi.ui.com |
| UL 294 level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| UL 294 statement | Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. |
| PoE cabling requirements | Cable 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable. |
| CAN/ULC-60839-11-1 Grade | Grade assignment: I |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Document number, and issue date and/or revision level | UA-Hub, Ver 02 |
LEDs
| PoE in | Steady white: Pending adoption Steady blue: Adopted Alternating white/blue: Firmware updating |
| PoE out | Blinking white: Active signal |
| Input terminals | Blinking white: Active signal |
| Output relays | Blinking white: Relay triggered |
| Management application | UniFi Access: Version 1.22.17 and later |
Inhoud verpakking:
UA-Hub, DIN-rail, zelftappende schroeven, schroefankers
